- BFT LUX Operator
- Suitable for residential, industrial and multi-residential use
- 230V
- Intensive Use
- Swing gates up to 3m wide and weighing up to 300 kg
- Hydraulic operator
- All aluminium structure with high-resistance anodising treatment
- The slowdown during closing (R versions) guarantees silent, smooth movements on even the biggest gate
- Max duty cycle : 500/24 hrs
- Available in both reversible and irreversible versions, with maximum precision in torque control guaranteed by by-pass valves
- 24V available
Technical Secifications
- LUX / LUX 2B*
- LUX FC 2B
- Control unit
- RIGEL5
- RIGEL5
- Power supply
- 230V
- 230V
- Power input
- 250W
- 250W
- Useful rod stroke
- 270mm
- 280mm
- Maximum opening angle
- 123°
- 123°
- Operation time through 90°
- 17sec.
- 17sec.
- Slowdown
- No
- No
- Impact reaction
- Solenoid Lock / Open/close hydraulics*
- Open/close hydraulics
- Release Reversible Triangle key
- Reversible
- Triangle key
- Frequency of use
- Very intensive
- Very intensive
- Environmental conditions
- from -10°C to 60°C
- from -10°C to 60°C
- Actuator weight
- 8.7kg
- 8.7kg
more Technical Specifications
- LUX GVS
- LUX R 2B
- Control unit
- RIGEL 5
- RIGEL 5
- Power supply
- 230V
- 230V
- Power input
- 250W
- 250W
- Useful rod stroke
- 390mm
- 250mm
- Maximum opening angle
- 130°
- 123°
- Operation time through 90°
- 28sec.
- 15sec.
- Slowdown
- No
- Yes
- Impact reaction
- Hydraulic clutch
- Hydraulic clutch
- Locking
- Solenoid Lock
- Open/close hydraulics
- Release
- Triangle key
- Triangle key
- Frequency of use
- Very intensive
- Very intensive
- Environmental conditions
- from -10°C to 60°C
- from -10°C to 60°C
- Actuator weight
- 13.2kg
- 8.7kg
