- FAAC Tag 10 Card Reader
- The TAG 10 magnetic card reader can be used in access control systems for both pedestrians and vehicles
Technical Specifications
- TAG 10
- Container
- Plastic
- Power supply voltage
- 12 Vdc (from control board)
- Electrical connections
- Multipolar cable, screened 5 x 0.5
- Max. distance between reader & control unit
- 100 Metres
- Operating ambient temperature
- -10 ºC to +55 ºC
- Installation
- wall mounted or column mounted
- Buzzer
- can be turned off
- Dimensions (LxHxD) in mm
- 70 x 95 x 44
- Reading Distance
- 10cm
- Protection Level
- IP54
